Specifications
Note: Specifications and design subject to change without notice.
General Specifications
Configuration Tricycle vehicle with 2-wheel traction drive and rear wheel steering.
Engine
Briggs & Stratton–Daihatsu, 4-cycle, 3-cylinder, liquid cooled, vertical OHV, diesel
engine with centrifugal water pump. 18.4 hp (13.7 kW); governed to a maximum
speed of 3200 RPM. 51.9 cu. in. (850 cc) displacement. Forced lubrication gear
pump. Mechanical centrifugal governor. Mechanical fuel transfer pump. Fuel
filter/water separator with replaceable filter element. 12 volt (1 kW) starter. Heavy
duty remote mounted air cleaner spin-on oil filter.
Radiator Side mounted industrial radiator, 7 fins per inch. Approx. 5 quart (4.7 liter) capacity.
Electrical
12 volt Group 55, 450 cold cranking amps at 0°F (–18°C) ,75 minute reserve
capacity at 80°F (27°C). 40 amp alternator with regulator/rectifier. Seat switch,
PTO, parking brake, and traction interlock switches. Indicator light when cutting
units are running.
Fuel Capacity 6.5 gallons
Traction Drive
High torque hydraulic wheel motors. 2-wheel drive. Oil cooler and shuttle valve
provide positive closed-loop cooling. Optional 3–wheel drive kit.
Hydraulic Oil
Capacity/Filter
Remote mounted, 2.3 gallon (8.7 liter) oil reservoir. 25 micron remote mounted spin
on filter.
Ground Speed
Infinitely variable speed selection in forward and reverse
Mowing speed: 0–5 mph (0–8 km/h)
Transport speed: 0–8 mph (0–13 km/h)
Reverse speed: 0–3 mph (0–4.8 km/h).
Tires/Wheels
Two front traction drive tires, 20 x 10-8 tubeless, 4-ply rating. Rear steering tire and
tube; 20 x 8-8, 4-ply rating. Demountable front rims. Recommended tire pressure:
16–20 psi front and rear tires.
Frame Frame consists of formed steel, welded steel, and steel tubing components.
Steering Pinion and sector gear with solid drag link to rear steer wheel arm
Brakes
Service braking accomplished through dynamic characteristics of hydrostat.
Parking or emergency brake is actuated by ratchet hand lever on the operator’s
left-hand side.
Controls
Foot operated traction pedal and traction pedal stop. Hand operated throttle,
ignition switch, reel engagement switch, reel unit lift lever, parking brake, and seat
adjustment.
Gauges and Protective
Systems
Hour meter. Warning lights: oil pressure, water temperature, amps, glow plug and
reel engagement light. High water temperature shut-down. Engine preheat
incorporated into ignition switch.
Seat Adjustable to operator weight, fore and aft, w/removeable fold-up armrests
Cutting Unit Lift Hydraulic lift with automatic reel shut-off
