Service Interval Chart
Caution
If you leave the key in the ignition switch, someone could accidently start the engine and
seriously injure you or other bystanders.
Remove the key from the ignition and disconnect the wir
e from the spark plug befor
e you do any
maintenance. Set the wire aside so that it does not accidentally contact the spark plug.
