Tilt-Steering Pedal
G453181
Press the tilt-steering pedal
and raise or lower the steering
tower to a comfortable operating
position.
Traction Pedal
G453193
Move forward—press the top of the
pedal.
Stop the machine—reduce foot
pressure on the pedal and allow it to
return to the center (neutral) position.
Note: In emergency braking
situations, remove your foot from the
traction pedal and then pivot the
parking-brake switch forward.
Move backward—press the bottom
of the pedal.
Product Overview: Controls Page 4–5 3464-482 A
