G414734
1.
Close
and
latch
the
screen.
2.
Insert
the
ball
pin
through
the
screen
latch
.
Tilting
the
Seat
G443836
1.
Unlatch
the
seat
base
.
2.
T
ilt
the
seat
and
base
open
.
3.
Support
it
with
the
prop
rods
.
Lowering
the
Seat
1.
Rotate
the
seat
slightly
,
and
lift
the
front
prop
rod
out
of
the
dent
of
the
seat-support
slot.
2.
Carefully
lower
the
seat
until
it
latches
securely
.
3464-482A
Page
6–7
Maintenance:
Pre-Maintenance
Procedures
86
88
