20
Emptying the Grass Collector
When the collector warning light (Fig. 5) comes on and the
buzzer sounds, the grass collector is full and must be
emptied.
Important To prevent the discharge tunnel from getting
clogged, disengage the blades (PTO) when the warning
buzzer sounds.
1. Disengage the blades (PTO) and move the throttle to the
Slow position.
2. Pull out the telescoping dump lever and push it forward
and down to empty the grass collector (Fig. 16).
Figure 16
1. Pull up 2. Push forward and down
3. Slowly pull the dump lever upward to return the grass
collector to the operating position.
Towing Attachments
The tractor is equipped for towing attachments with a
maximum weight of 150 kg (331 lb.).
1. Remove the grass collector; refer to Removing the
Grass Collector on page 36.
2. Install the attachment to the towing hitch located at the
lower rear part of the tractor (Fig. 17).
1
Figure 17
1. Towing hitch
