ChuteAssemblyInstallation(continued)
g352575
Figure123
5.Installtherearbackdoorontotheunit.
6.Installtherearheight-of-cutplates.RearHeight-of-CutRemoval(page6–12)
7.Modelsequippedwithelectricstartonly,connectthebatterybyinstalling
thepositivecablerst,thenthenegativecabletothebattery.Installthefoam
padandbatterycover.Securethebatterycoverwith2(M4.2x2.0)screws.
Torquethescrewsto2.26±0.34N•m(20±3in-lbs).
8.Modelsequippedwiththe60vpowerhead,installtheharnesstothe
powerhead.
DeckReplacement
DeckRemoval
1.Parkthemachineonalevelsurface,stoptheengineandwaitforallmoving
partstostop.
2.Modelsequippedwiththe60vpowerhead,removetheharnessfrom
powerhead.
3.Modelsequippedwithelectricstartonly,removethe2(M4.2x2.0)
screwssecuringthebatterycover.Removethebatterycoverandfoampad.
Disconnectthebatterybyremovingthenegativecablerst,thenthepositive
cablefromthebattery.
4.Removethegrassbaggerassemblyifattached.
5.RWDmodelsonly,removetheRWDtractioncable.RWDTractionCable
Removal(page5–8)
6.AWDmodelsonly,removetheAWDfrontandreartractioncables.AWD
FrontTractionCableRemoval(page5–14)AWDRearTractionCable
Removal(page5–16)
7.Removethebrakecable.BrakeCableRemoval(page5–4)
8.RemovetheLHhandleknobfromthecurvedhandle.RepeatontheRH
sideoftheunit.
9.Removethecurvedhandlefromthechassis.CurvedHandleRemoval
(Non—ElectricStartModelsOnly)(page5–37)CurvedHandleRemoval
(ElectricStartModelsOnly)(page5–40)
Deck:ServiceandRepairs
Page6–24
22InchAWD/RWDSteelDeckWalkPower
MowerServiceManual
3445-579RevA

Toro 21462 Specifications

General

Brand	Toro
Model	21462
Category	Lawn Mower
Type	Walk-Behind
Power Source	Gas
Engine	Briggs & Stratton
Engine Displacement	163cc
Mulching Capability	Yes
Rear Bagging	Yes
Side Discharge	Yes
Starter	Recoil
Engine Type	4-Cycle
Cutting Width	22 inches
Drive System	Personal Pace
Cutting Height	1.0 - 4.0 inches
Fuel Capacity	0.25 gallons
Wheel Size	8 inches (front), 10 inches (rear)
Oil Capacity	20 oz
