RWDFrontWheelReplacement
RWDFrontWheelRemoval
1.Parkthemachineonalevelsurface,stoptheengineandwaitforallmoving
partstostop.
2.Modelsequippedwiththe60vpowerhead,removetheharnessfrom
powerhead.
3.Modelsequippedwithelectricstartonly,removethe2(M4.2x2.0)
screwssecuringthebatterycover.Removethebatterycoverandfoampad.
Disconnectthebatterybyremovingthenegativecablerst,thenthepositive
cablefromthebattery.
4.Removethegrassbaggerassemblyifattached.
5.Usinga½inchwrench,removetheLH(3/8–16inch)shoulderboltfollowed
bythewheelandwasherfromthefrontpivotarm.RepeatontheRHsideof
theunit.
g352036
Figure129
1.Washer3.IdlerWheel
2.FrontPivotArm4.WheelBolt
RWDFrontWheelInstallation
1.Installthewasher,wheel,andLH(3/8–16inch)shoulderboltontothefront
pivotarm.T orquetheboltto35±1.69N•m(315±15in-lb).
Note:Afterinstallation,verifythepivotarmandwheelassemblyrotates
freelyandthatthespringarmengagestheindividualsettingsonthe
height-of-cutplatethroughallofheight-of-cutsettings.
Note:Lubricatetheinternaldiameterofthebushingsonthewheel
assembliesusinglithiummulti-purposegrease.
DriveSystem:ServiceandRepairs
Page7–6
22InchAWD/RWDSteelDeckWalkPower
MowerServiceManual
3445-579RevA

Toro 21462 Specifications

General

Brand	Toro
Model	21462
Category	Lawn Mower
Type	Walk-Behind
Power Source	Gas
Engine	Briggs & Stratton
Engine Displacement	163cc
Mulching Capability	Yes
Rear Bagging	Yes
Side Discharge	Yes
Starter	Recoil
Engine Type	4-Cycle
Cutting Width	22 inches
Drive System	Personal Pace
Cutting Height	1.0 - 4.0 inches
Fuel Capacity	0.25 gallons
Wheel Size	8 inches (front), 10 inches (rear)
Oil Capacity	20 oz
