RWDTransmissionRemoval(continued)
6.Removetherearheight-of-cutassemblies.RearHeight-of-CutRemoval
(page6–12)
7.Removethebeltfromtheenginepulley.
8.Removethetransmissionandtransmissionbelt.
RWDTransmissionInstallation
1.Installthetransmissionandtransmissionbelt.
2.Installthebeltontotheenginepulley.
3.Installtherearheight-of-cutassemblies.RearHeight-of-CutInstallation
(page6–16)
4.Installthetractioncable.RWDTractionCableInstallation(page5–11)
5.Modelsequippedwithelectricstartonly,connectthebatterybyinstalling
thepositivecablerst,thenthenegativecabletothebattery.Installthefoam
padandbatterycover.Securethebatterycoverwith2(M4.2x2.0)screws.
Torquethescrewsto2.26±0.34N•m(20±3in-lbs).
6.Modelsequippedwiththe60vpowerhead,installtheharnesstothe
powerhead.
AWDRearTransmissionReplacement
AWDRearTransmissionRemoval
1.Parkthemachineonalevelsurface,stoptheengineandwaitforallmoving
partstostop.
2.Modelsequippedwiththe60vpowerhead,removetheharnessfrom
powerhead.
3.Modelsequippedwithelectricstartonly,removethe2(M4.2x2.0)
screwssecuringthebatterycover.Removethebatterycoverandfoampad.
Disconnectthebatterybyremovingthenegativecablerst,thenthepositive
cablefromthebattery.
4.Removethegrassbaggerassemblyifattached.
5.RemovetheAWDreartractioncable.AWDRearTractionCableRemoval
(page5–16)
6.Removethebrakecable.BrakeCableRemoval(page5–4)
7.Removethebladefromtheenginecrank.RefertotheproductOperator’s
Manualforthebladeremovalprocedures.
8.Removethe2(1/4–10inch)LHscrewssecuringtherearbafetothedeck.
RepeatontheRHsideoftheunit.
DriveSystem:ServiceandRepairs
Page7–12
22InchAWD/RWDSteelDeckWalkPower
MowerServiceManual
3445-579RevA

Toro 21462 Specifications

General

Brand	Toro
Model	21462
Category	Lawn Mower
Type	Walk-Behind
Power Source	Gas
Engine	Briggs & Stratton
Engine Displacement	163cc
Mulching Capability	Yes
Rear Bagging	Yes
Side Discharge	Yes
Starter	Recoil
Engine Type	4-Cycle
Cutting Width	22 inches
Drive System	Personal Pace
Cutting Height	1.0 - 4.0 inches
Fuel Capacity	0.25 gallons
Wheel Size	8 inches (front), 10 inches (rear)
Oil Capacity	20 oz
