AWDRearTransmissionInstallation(continued)
13.Modelsequippedwiththe60vpowerhead,installtheharnesstothe
powerhead.
AWDFrontTransmissionReplacement
AWDFrontTransmissionRemoval
1.Parkthemachineonalevelsurface,stoptheengineandwaitforallmoving
partstostop.
2.Modelsequippedwiththe60vpowerhead,removetheharnessfrom
powerhead.
3.Modelsequippedwithelectricstartonly,removethe2(M4.2x2.0)
screwssecuringthebatterycover.Removethebatterycoverandfoampad.
Disconnectthebatterybyremovingthenegativecablerst,thenthepositive
cablefromthebattery.
4.Removethegrassbaggerassemblyifattached.
5.RemovetheAWDfrontwheels.AWDFrontWheelRemoval(page7–7)
6.Removetheupperintakefromthedeck.UpperIntakeRemoval(page6–18)
7.Removethetransmissionreturnspringfromtheshoulderboltand
transmissionbracket.
g360054
Figure146
8.Removethefronttractioncableanchorfromthetransmissionmountandthe
cablereturnspringfromthedeck.
22InchAWD/RWDSteelDeckWalkPowerMowerService
Manual
Page7–17
DriveSystem:ServiceandRepairs
3445-579RevA
