Toro After Groundsmaster 4500-D User Manual

Traction Pedal
G468096
Move forward—press the top of the
pedal.
Note: To achieve no load, maximum
ground speed, press the engine-speed
switch to high idle and then fully press
the traction pedal.
Stop the machine—reduce foot
pressure on the pedal and allow it to
return to the center (neutral) position.
Move backward—press the bottom
of the pedal.
Note: Ground speed depends on how far you press the pedal.
Tilt-Steering Pedal
G453181
Press the tilt-steering pedal
and raise or lower the steering
tower to a comfortable operating
position.
Brake Pedals
The 2 foot pedals operate individual wheel brakes for turning assistance and to aid in
obtaining better side hill traction.
3466-702A Page 4–2 Product Overview: Controls
