Setup
Note: Determine the left and right sides of the machine from the normal operating position.
Note: Use this chart as a checklist to ensure that all parts necessary for assembly have been received. Without these parts,
total set-up cannot be completed. Some parts may have already been assembled at the factory.
Description Qty. Use
Steering wheel
Cover
1
1
Install steering wheel
Manual tube
R–clamp
Capscrew
Washer
1
2
2
2
Install on right underside of seat
Roll pin
Capscrew 5/16–18 x 1–3/4” lg.
Locknut 5/16–18
1
2
2
Secure universal shaft to implement
Cylinder pin
Cotter pin 3/16 x 1–1/2”
2
4
Secure deck lift arms to lift cylinders
Brake return springs 2 Mount to deck lift arms
Ignition key 1
Operator’s Manual (Traction Unit)
Parts Catalog
2
1
Registration card 1 Fill out and return to Toro
