4. Coat the terminal with sealant such as Grafo 112X, Toro
Part No. 505-47 and install the rubber boot onto
positive terminal.
Check Tire Pressure
The tires are over–inflated for shipping. Therefore, release
some of the air to reduce the pressure. Correct air pressure
in front and rear tires is 20 psi.
Install Rear Weight
The Groundsmaster 225 Traction Unit complies with ANSI B71.4–1999 Standard when equipped with rear weight. 55 lbs. of
rear weight is installed, at the factory, on the Groundsmaster 225 Traction Unit. Use chart below to determine combinations
of additional weight required. Order parts from your local Authorized Toro Distributor.
Rear
Weight
Required
Left Side Weight
Required
Weight
Part
Number
Weight Description Qty.
52” Rear Discharge Deck
(Model 30568)
or
52” Side Discharge Deck
(Model 30555)
0 lb. 0 lb. – – –
52” Side Discharge Deck
with 9 cu. ft. Hopper
0 lb. 0 lb. – – –
52” Side Discharge Deck
with 15 cu. ft. Hopper
0 lb. 250 lb. *77–6700
&
92–9670
&
24–5780
&
24–5790
325–8
3253–7
3–8847
3217–9
75 lb. Wheel Weight
&
Bracket Kit
&
Rear Weight Kit
&
Rear Weight Kit
Capscrew–1/2–13 x 2”
Lockwasher–1/2
Spacer
Nut–1/2
1
1
2
1
62” Side Discharge Deck
(Model 30551)
70 lb. 0 lb. 24–5780 Rear Weight Kit 1
62” Side Discharge Deck
with 9 cu. ft. Hopper
50 lb. 0 lb. 24–5780 Rear Weight Kit 1
62” Side Discharge Deck
with 15 cu. ft. Hopper
0 lb. 180 lb.* *77–6700
&
92–9670
&
24–5780
24–5790
325–8
3253–7
3–8847
3217–9
75 lb. Wheel Weight
&
Bracket Kit
&
Rear Weight Kit
Rear Weight Kit
Capscrew–1/2–13 x 2”
Lockwasher–1/2
Spacer
Nut–1/2
1
1
1
1
2
2
2
2
62” Guardian Recycler Deck
(Model 30569)
50 lb. 0 lb. 24–5780 Rear Weight Kit 1
72” Side Discharge Deck
(Model 30553)
85 lb. 0 lb. 24–5780
&
92–8763
Rear Weight Kit
&
Weight Kit–20 lb.
1
1
* 75 lb. wheel weight (included with 15 cu. ft. hopper) required on left wheel
