Figure29
1.Lockwheel
2.Weighttransferhand
wheel
2.Attherightsideofthemachine,loosenthelock
wheeloftheweighttransfermanifold1/2turn
counterclockwisewhileholdingthehandwheel
steady(Figure29).
3.Rotatetheweighttransferhandwheel(Figure
29)asfollows:
•counterclockwisetoreduceweighttransfer
•clockwisetoincreaseweighttransfer
Note:Therecommendedsettingfortheweight
transfer/tractionassistanceistoincreasethe
weighttransferuntilthecuttingunitsstart
tolift,thenrotatethehandwheel1/2turn
counterclockwise.
4.Tightenthelockwheel(Figure29).
ClearingtheCuttingUnits
WARNING
Neverattempttorotatethecuttingunitsby
hand.Residualpressureinthehydraulic
systemcouldcausethecuttingunit(s)
torotatesuddenlywhenyoureleasethe
blockage,whichmaycauseseriousinjury.
•Alwayswearprotectiveglovesandusea
suitablestrongwoodeninstrument.
•Ensurethatthewoodeninstrumentts
betweenthebladesandthroughthereel
andislongenoughtoprovideleverageto
releasetheblockage.
1.Parkthemachineonalevelsurface.
2.MovethetractionpedaltotheNEUTRALposition,
engagetheparkingbrake,andshutoffthe
cuttingunits.
3.Lowerthecuttingunitstothegroundorsecurely
locktheminthetransportpositions.
4.Shutofftheengine,removethekey,andwaitfor
allmovingpartstostop.
5.Releaseallstoredenergydevices.
6.Checkthatallmovingpartsarestationary.
7.Usingasuitablestrongwoodeninstrument,
removetheblockage.Ensurethatthewooden
instrumentisproperlysupportedinthecutting
unitandavoidusingexcessiveforcetoprevent
damage.
8.Removethewoodeninstrumentfromthecutting
unitbeforestartingtheengine.
9.Repairoradjustthecuttingunitifrequired.
OperatingTips
BecomingFamiliarwiththe
Machine
Beforemowinggrass,practiceoperatingthemachine
inanopenarea.Startandshutofftheengine.
Operateinforwardandreverse.Lowerandraisethe
cuttingunit,andengageanddisengagethem.When
youfeelfamiliarwiththemachine,practiceoperating
itupanddownslopes.
