1.Ventscrew
2.Drainvalve(waterseparatorlter)
4.Tightenthedrainvalveatthebottomofthelter
canisterandclosetheventscrewatthetopof
thecanistermount.
5.Primethefuelsystem;refertoPrimingtheFuel
System(page45).
PrimingtheFuelSystem
Primethefuelsystemunderthefollowingconditions:
•Beforestartingtheengineforthersttime.
•Ifyourunoutoffuelandthenaddnewfueltothe
system.
•Afterperformingmaintenancetothefuelsystem,
suchaschangingthefuellter,drainingthewater
separator,orreplacingafuel-systemcomponent.
Toprimethefuelsystem,rotatethekeyswitchtothe
ONpositionfor10to15secondstoallowtheelectric
fuelpumptoprimethefuelsystem.
Important:Donotusethestartermotortocrank
theenginetoprimethefuelsystem.Youwill
damagethestartermotor.
ReplacingtheFuel-Water
Filter
ServiceInterval:Every500hours
Important:Replacethefuelltercanister
periodicallytopreventwearofthefuelinjection
pumpplungerortheinjectionnozzle,duetodirt
inthefuel.
1.Placeacleancontainerunderthefuellter
canister(Figure56).
2.Drainthefuelltercanister;refertoServicing
theWaterSeparator(page44).
3.Cleantheareaaroundthefuellterandlter
head(Figure56).
g292477
Figure56
1.Filterhead
2.Fuellter
4.Removetheltercanisterandcleanthelter
head(Figure56).
5.Lubricatethegasketontheltercanisterwith
cleandieselfuel.
6.Installthenewltercanisterbyhanduntilthe
gasketcontactsmountingsurface.
7.Primethefuelsystem;refertoPrimingtheFuel
System(page45).
45
