g017810
g017810
Figure68
FrontLiftAssemblies
•2(eachside)lift-arm-cylinderbushings(Figure69)
•2lift-arm-balljoints(Figure70)
g020455
Figure69
g011551
Figure70
SideMowerDecks
•1caster-fork-shaftbushing(Figure71)
•2(eachside)spindle-shaftbearings—located
underthepulley
•1idler-arm-pivotbushings—locatedontheidler
arm
g011557
Figure71
SideLiftAssemblies
•6mainlift-armbushings(Figure72andFigure73)
•2bell-crank-pivotbushings(Figure74)
•4reararmbushings(Figure74)
•4lift-cylinderbushings(Figure75)
g011552
Figure72
g011553
Figure73
