19
Carburetor and Linkage Exploded View
Control Asm. Bracket
Governor Spring
Governor Rod
Throttle Return
Spring
Governor
Arm
Spacer
Gasket
Insulator
Heat Shield
Gasket
3
Governor
Pinch Bolt
