27
Engine Service – Lower End
Crankcase / Governor Exploded View and Service Information
Governor Exploded Views
3
Aux. Oil Drain
15.5 ft-lbs (21 Nm)
Sealing Washer
7.5 ft-lbs (10 Nm)
Governor
Holder
Gasket
Pin
Weight
Washer
Slider
Clip
Washer
Shaft
Governor
Holder
Governor Asm.
