Specifications
Note: Specifications and design subject to change without notice.
General Specifications
Engine
Kubota, four–cycle, four cylinder, 134 cu–in. displacement, water cooled diesel
engine. Rated 40 hp @ 2300 rpm, 23:1 compression ratio. Low idle – 1200 rpm,
high idle – 2500 rpm. Injection Timing – 17–18 BTDC. Oil capacity is 8 qt. (7.6 L)
with filter.
Cooling System Capacity is 3.7 gal. (14 L) of 50/50 mixture of ethylene glycol anti–freeze.
Fuel System Capacity is 15 gal. (56.8 L) .
Hydraulic System
Reservoir capacity is 9.3 gal. (35.2 L) and total system capacity is 18.2 gal. (69 L).
Replaceable breather element. Replaceable spin–on filter element.
Traction System Ground speed is 0–12.5 mph (0–20 km/h).
Cutting Unit Drive System
Adjustable reel speed to match clip to ground speed. Backlap reel speed is 385
rpm.
Seat
Adjusts 6 in. (15.2 cm) forward and backward. Adjustable backrest and
three–positions for operator weight. Integral seat switch at rear of bottom seat
cushion.
Diagnostic System
Test ports for traction system, cutting unit drive system, lift/counterbalance,
lift/relief, steering circuits and charge pressure are located near individual
components.
Steering System Automotive type, full power.
Brakes
Hand brake automatically locks traction linkage in neutral. With traction motor
wheel locks engaged, twin disc brakes provide positive, emergency braking.
Electrical System 12 volt, 66 amp hour (DIN) battery and 40 amp alternator. Negative ground.
Interlock System
Designed to stop engine if operator gets off seat while cutting unit drive lever is
either in forward or reverse. Prevents engine from starting unless parking brake is
engaged, traction pedal is in neutral and cutting units are disengaged. Low
hydraulic oil level and high engine temperature protection systems stop engine
from running.
Warning Systems
Water in fuel, hydraulic oil filter, engine coolant temperature, engine oil pressure,
voltage indicator, air cleaner clogged, hydraulic oil temperature and hydraulic oil
level.
Ground Clearance Approx. 7 in. (17.8 cm)
Height of cut
5 Blade Cutting Unit: 1 – 3 in. (25 – 76 mm)
7 Blade Cutting Unit: 3/8 – 1 3/4 in. (9.5 – 45 mm)
11 Blade Cutting Unit: 3/8 – 3/4 in. (9.5 – 19 mm)
Wheel Thread 53 in. (135 cm)
Wheel Base 57 in. (145 cm)
Operating Circle 60 in. (152 cm)
Reel Speed
800 – 1000 rpm
Note: 1200 rpm is attainable with a special coupler.
Clip
5 Blade Cutting Unit: .176 in. per mph (.352 in. at 2 mph – 1.32 in. at 7.5 mph)
7 Blade Cutting Unit: .126 in. per mph (.252 in. at 2 mph – .945 in. at 7.5 mph)
11 Blade Cutting Unit: .080 in. per mph (.16 in. at 2 mph – .600 in. at 7.5 mph)
