Toro TS120 User Manual

13
6.3 Setting the sector
With this impact sprinkler the sector setting is innitely variable.
You can adjust the area to be watered by pulling or pressing on the relevant end of the top
or bottom spring stop.
Setting the sector angle
WARNING!
Innitely variable setting is possible by pulling (not pressing) on the relevant end of
the top or bottom spring stop
Spring stop
Spring stop
Apply pressure here

Toro TS120 Specifications

General

Brand	Toro
Model	TS120
Category	Irrigation System
Language	English
