4
Securing screw
Securing screw
T
urf cup
Cover for cable
compartment
Cover for cable
compartment
Manual ON/OFF/Auto
control module
Housing
Guide Housing
Main water
connection (1½”)
Cable inlet
openings
3.2 Views TS120 Impact Sprinkler
with VIH and T
urfCup
5
7
Table of Contents
Default Chapter
2
Table of Contents
2
1 General
3
2 Safety
3
Use of Symbols in These Operating Instructions
3
Proper Use
4
Clearly Improper Use
4
Safety Information
4
Dangers of Failing to Observe Safety Instructions
4
3 Description
5
Views TS120 Impact Sprinkler with VIH
5
Views TS120 Impact Sprinkler with VIH and Turfcup
6
Special Tools
7
4 Technical Data
8
5 Assembly, Set-Up and Installation
8
Hazard Warnings
8
Installation Instructions
8
TS120 Impact Sprinkler Installation Diagram
9
Cabling
11
6 Commissioning and Operation
13
Potential Danger
13
Commissioning
14
Setting the Sector
15
7 Decommissioning and Preparing for Winter
16
Maintenance and Repair Work
17
Maintenance
17
Changing the Nozzles
17
Removing the Valve Insert
19
Removal / Installation of the Control Unit
20
9 Troubleshooting
22
Sprinkler Malfunctions
22
