BeltMaintenance
CheckingtheConditionof
theHydraulicPumpBelt
ServiceInterval:Yearly
Checktheconditionofthehydraulicpumpbelt(Figure
52)yearly.HaveanAuthorizedServiceDealer
replaceitifitbecomesdamagedorworn.
g004356
Figure52
1.Hydraulicpumpbelt
ControlsSystem
Maintenance
AdjustingtheControls
Thefactoryadjuststhecontrolsbeforeshippingthe
machine.However,aftermanyhoursofuse,you
mayneedtoadjustthetractioncontrolalignment,
theNEUTRALpositionofthetractioncontrol,andthe
trackingofthetractioncontrolinthefullforward
position.
Important:Toadjustthecontrolsproperly,
completeeachprocedureintheorderlisted.
AdjustingtheTractionControl
Alignment
Ifthetractioncontrolbardoesnotrestushand
squarewiththereferencebarwheninthefull
backwardposition,immediatelycompletethefollowing
procedure:
1.Parkthemachineonalevelsurface,engagethe
parkingbrake,andlowertheloaderarms.
2.Shutofftheengineandremovethekey.
3.Pullstraightbackonthetractioncontrolsothe
frontofthecontrolcontactsthereferencebar
(Figure53).
g004190
Figure53
1.Frontofthecontrol(outof
alignment)
2.Referencebar
4.Ifthefrontofthetractioncontroldoesnotrest
squareandushwiththereferencebar,loosen
theangenutandboltinthestemofthetraction
control(Figure54).
