Toro Workman MD Service Manual

Workman MD/MDXPage 7 -- 20Chassis
Frame Pivot Yoke
1. Flange nut (4 used)
2. Shock absorber (2 used)
3. Cap screw (4 used)
4. Rubber bumper
5. Flat washer
6. Lock nut (4 used per side)
7. Cap screw (2 used per shock)
8. LH A--arm
9. Grease fitting (1 used per arm)
10. Screw
11. Cap screw
12. RH A--arm
13. Lock washer
14. Front frame
15. Pivot yoke
16. Flange head screw (4 used)
17. Flat washer (4 used)
18. Hardened washer
19. Cap screw (2 used per arm)
20. Ground cable
Figure 11
FRONT
RIGHT
240 to 290 ft--lb
(326 to 393 N--m)
6
9
19
6
19
2
5
7
6
14
4
16
11
18
3
17
1
15
7
10
13
8
12
20
