Workman MD/MDX Page 7 -- 33 Chassis
Disassembly (Fig. 21)
1. Park machine on a level surface, stop engine, set
parking brake and remove key from the ignition switch.
WARNING
Before jacking up the machine, review and follow
Jacking Instructions in Chapter 1 -- Safety.
2. Chock wheels not being jacked up. Jack front wheel
off the ground and place appropriate jack stand beneath
the frame to support vehicle.
3. Remove front wheel from machine (see Lower
Steering and Front Wheel Removal).
4. Clean hydraulic brake line area of brake caliper to
prevent contamination. Loosen and disconnect brake
line from caliper. Plug brake line and position it away
from caliper.
5. Remove two (2) cap screws and lock washers that
secure the brake caliper to the spindle.
6. Slide brake caliper from brake rotor and remove cali-
per from machine.
Assembly (Fig. 21)
1. Slide brake caliper onto brake rotor. Make sure that
rotor is between brake pads.
2. Align caliper mounting holes with spindle. Secure
caliper with two (2) cap screws and lock washers.
3. Install brake hose to caliper.
4. Install front wheel assembly.
5. Lower machine to ground.
6. Torque lug nuts in a crossing pattern from 45 to 65
ft--lb (62 to 88 N--m).
7. Bleed brakes (see Bleed Brake System in this sec-
tion).
CAUTION
After servicing brake system components, al-
ways check the brakes in a wide open, level area
that is free of other persons and obstructions.
8. Check brake operation.
