OperatingtheMower

Blade-ControlSwitch(PTO)

Theblade-controlswitch(PTO)startsandstopsthe

mowerbladesandanypoweredattachments.

EngagingtheBlade-Control

Switch(PTO)

Note:Engagingtheblade-controlswitch(PTO)with

thethrottlepositionathalforlesscausesexcessive

weartothedrivebelts.

g008945

Figure23

DisengagingtheBlade-Control

Switch(PTO)

g009174

Figure24

OperatingtheThrottle

YoucanmovethethrottlecontrolbetweenFASTand

SLOWpositions(Figure25).

AlwaysusetheFASTpositionwhenengagingthePTO.

g008946

Figure25

OperatingtheChoke

Usethechoketostartacoldengine.

1.Pullupthechokeknobtoengagethechoke

beforeusingthekeyswitch(Figure26).

2.Pushdownthechokeknobtodisengagethe

chokeaftertheenginehasstarted(Figure26).

g008959

Figure26

1.ONposition2.OFFposition

Table of Contents3
Safety5
General Safety5
Slope Indicator6
Safety and Instructional Decals7
Product Overview14
Controls14
Specifications16
Attachments/Accessories16
Before Operation17
Before Operation Safety17
Adding Fuel18
Performing Daily Maintenance18
Breaking in a New Machine19
Using the Rollover-Protection System19
(Rops)19
Using the Safety-Interlock System20
Positioning the Seat21
Changing the Seat Suspension21
Adjusting the Rear-Shock Assemblies21
Using Attachments and Accessories22
During Operation22
During Operation Safety22
Entering the Operator's Position25
Operating the Parking Brake25
Operating the Mower Blade-Control Switch (PTO)26
Operating the Throttle26
Operating the Choke26
Starting the Engine27
Shutting off the Engine27
Using the Motion-Control Levers28
Driving the Machine29
Using the Side Discharge30
Adjusting the Height of Cut30
Adjusting the Anti-Scalp Rollers31
Operating Tips32
After Operation32
After Operation Safety32
Using the Fuel-Shutoff Valve33
Using the Drive-Wheel Release Valves33
Transporting the Machine34
Maintenance36
Maintenance Safety36
Recommended Maintenance Schedule(S)36
Lubrication38
Greasing the Machine38
Greasing the Caster-Wheel Hubs39
Engine Maintenance40
Engine Safety40
Identifying the Engine40
Servicing a Kawasaki ® Engine40
Servicing a Toro Engine45
Cleaning the Blower Housing49
Cleaning the Engine Screen49
Cleaning the Cooling System50
Checking the Spark Arrester50
Replacing the Emissions-Air Intake Filter51
Fuel System Maintenance51
Replacing the Fuel Filter51
Servicing the Fuel Tank52
Electrical System Maintenance52
Electrical System Safety52
Servicing the Battery52
Servicing the Fuses54
Drive System Maintenance55
Checking the Seat Belt55
Adjusting the Tracking55
Checking the Tire Pressure56
Checking the Wheel Lug Nuts56
Brake Maintenance56
Adjusting the Parking Brake56
Belt Maintenance58
Inspecting the Belts58
Replacing the Mower Belt58
Replacing the Hydraulic Pump-Drive Belt59
Controls System Maintenance60
Adjusting the Control-Handle Position60
Adjusting the Motion-Control Linkage61
Hydraulic System Maintenance62
Hydraulic System Safety62
Hydraulic Fluid Specifications62
Checking the Hydraulic Fluid Level62
Changing the Hydraulic Fluid and Filters62
Bleeding the Hydraulic System64
Mower Deck Maintenance65
Blade Safety65
Servicing the Cutting Blades65
Adjusting the Side-To-Side Leveling and the Blade Slope68
Removing the Mower Deck70
Replacing the Grass Deflector71
Cleaning72
Cleaning under the Mower Deck72
Cleaning the Suspension System72
Disposing of Waste72
Storage73
Storage Safety73
Cleaning and Storage73
Troubleshooting74
Schematics76
