ControlsSystem
Maintenance
Adjustingthe
Control-HandlePosition
Iftheendsofthelevershitagainsteachother,referto
AdjustingtheMotion-ControlLinkage(page61).
AdjustingtheHeight
Youcanadjustthemotioncontrollevershigheror
lowerformaximumcomfort.
1.Parkthemachineonalevelsurface,disengage
theblade-controlswitch(PTO),andengagethe
parkingbrake.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Removethehardwareholdingthecontrollever
tothecontrol-armshaft.
g035858
Figure79
1.Bolts
3.Controllever
2.Slottedhole4.Control-armshaft
4.Movethecontrollevertothenextsetofholes.
Securetheleverwiththehardware.
5.Repeattheadjustmentfortheoppositecontrol
lever.
AdjustingtheTilt
1.Parkthemachineonalevelsurface,disengage
theblade-controlswitch(PTO),andengagethe
parkingbrake.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Loosentheupperboltholdingthecontrollever
tothecontrolarmshaft.
4.Loosenthelowerboltjustenoughtopivotthe
controlleverforeoraft.Tightenbothboltsto
securethecontrolinthenewposition.
5.Repeattheadjustmentfortheoppositecontrol
lever.
g009195
Figure80
60
