Lubrication
GreasingtheMachine
ServiceInterval:Every25hours—Greasethefront
casteraxles(moreoftenindirtyor
dustyconditions).
Every50hours—Greasethepump-idlerpivot.
Greasethemachinemoreoftenindirtyordusty
conditions.
GreaseType:No.2lithiumormolybdenumgrease
1.Parkthemachineonalevelsurface,disengage
theblade-controlswitch,andengagetheparking
brake.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Cleanthegreasettingswitharag.
Note:Scrapeanypaintoffthefrontofthe
tting(s).
4.Greasethepumpidler-pulleypivotwith1or2
pumpsofgrease(Figure41).
5.Greasethefrontcasteraxles(Figure41).
g296411
Figure41
1.Pump-idlerpivot
2.Casteraxle
6.Wipeupanyexcessgrease.
