Toshiba 1600EP Series User Manual

32
1600EP Series Instruction Manual
Special Display Screens
The special Data Display screens show below depict settings that can be viewed (but not changed locally)
on the LCD panel. These settings can only be changed through the RS232C or optional RemotEye
network card.
Continued from Timer Start Data screen page 31
Continued from Timer Stop Data screen page 31
Continued from Weekly Schedule Data screen page 31
Continued from Special Operate Data screen page 31
Continued from Special Off Time Data screen page 31
NOTES
To access the data setting screens pess the SET/MONITOR key from any of the (see page 33)
Data Settings screens.
Pressing the SHIFT/SELECT and CANCEL key returns to the Data Display screens.
1.
2.
STOP 1
###.## - ###.##
WEEKLY (MON)
###.## - ###.##
START 1
###.## - ###.##
START TIME 1 DAY
##HR ##MIN ##SEC
STOP TIME 1 DAY
##HR ##MIN ##SEC

Toshiba 1600EP Series Specifications

General

Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-15°C to 50°C (5°F to 122°F)
Communication Interface	RS-232
Humidity	0% to 95% relative humidity (non-condensing)
Battery Type	Valve-Regulated Lead-Acid (VRLA)

Summary

Product Use and Warranty Restrictions

Qualified Personnel Only

Defines requirements for personnel performing installation and maintenance.

Purpose

Toshiba Customer Support Center

Contact information for assistance with application or operational issues.

General Safety Instructions

Symbols

Explains safety alert, prohibited, mandatory, and hazard symbols used in the manual.

Signal Words

IMPORTANT SAFETY INSTRUCTIONS

QUALIFIED PERSONNEL ONLY

Defines qualifications and responsibilities for personnel working with the UPS.

Product Description

Application and Use

Outlines typical applications for the UPS in office environments.

Output Rating

Lists model capacities and their corresponding output ratings.

Power Backup and Conditioning

Details how the UPS provides backup power and protects loads from disturbances.

Inspection/Storage/Disposal

Storage Guidelines

Provides guidelines for storing the UPS to maintain its condition.

Disposal Information

Information on contacting agencies for proper disposal of electrical components and batteries.

Installation Precautions

Conductor Routing and Grounding

Specifies how to route wires and ensure proper grounding for safety and noise reduction.

Operating Precautions

Equipment Warning Labels

UPS Connections

Terminal Block

Illustrates the terminal block and wiring connections for 208/240 volt units.

Communication Interfaces

Remote Contacts

Details the remote contacts interface and DB9 male connector pin assignments.

UPS Stop Signal Operation

RS-232C

RemotEye II Network Card

Describes the optional network card for remote UPS management.

UPS Specifications

UPS Specifications: 3.6-8kVA Models

Environment

Lists environmental operating and storage temperature, humidity, and altitude.

Operation Diagnosis

Details battery check, input OV protection, battery lifetime, etc.

UPS Specifications: 10-22kVA Models

Environment

Lists environmental parameters like operating temperature and humidity.

Operation Diagnosis

Covers battery check, input OV protection, and internal temperature.

Operating the UPS

Battery Backup Time and Discharge Process

Explains battery backup duration and discharge process.

Starting the UPS

Stopping the UPS

Online Mode

Static-Bypass Mode (Stop Operation)

Describes power flow when the UPS is in bypass mode due to overload or fault.

Display and Keys

Front Panel Layout

Shows the components of the UPS front panel, including LCD and keys.

Data Display Screens

System Warning Messages

System Fault Messages

UPS Protection System

System Protection Functions

Details built-in UPS fault protection functions for various conditions.

Preventive Maintenance/Parts Replacement

Parts Replacement

Lists recommended replacement intervals for UPS components like capacitors, fuses, fans, and batteries.

External Layouts/Dimensions/Shipping Weights

Dimensional Data

Provides a table with physical dimensions for different UPS models.
