1600XP/XPi Series Installation and Operation Manual – 60616-012
10kVA – UH3G2L100C61T / H3BG2L100C61T
(Runtimes are approximate)
UPS ESTIMATED RUNTIME WITH ONLY INTERNAL BATTERIES @ .70pf
Rating PF Output
Voltage
Rated I Rated
Load %
Output
Watts
# Batt # Strings Nominal Runtime
10 0.7 240 41.67 0.10 700 24 1 288 86
10 0.7 240 41.67 0.20 1400 24 1 288 50
10 0.7 240 41.67 0.30 2100 24 1 288 32
10 0.7 240 41.67 0.40 2800 24 1 288 22
10 0.7 240 41.67 0.50 3500 24 1 288 16
10 0.7 240 41.67 0.60 4200 24 1 288 13
10 0.7 240 41.67 0.70 4900 24 1 288 10
10 0.7 240 41.67 0.80 5600 24 1 288 9
10 0.7 240 41.67 0.90 6300 24 1 288 8
10 0.7 240 41.67 1.00 7000 24 1 288 7
UPS ESTIMATED RUNTIME WITH INTERNAL BATTERIES AND 1 MATCHING BATTERY CABINET @ .70pf
Rating PF Output
Voltage
Rated I Rated
Load %
Output
Watts
# Batt # Strings Nominal Runtime
10 0.7 240 41.67 0.10 700 24 4 288 300
10 0.7 240 41.67 0.20 1400 24 4 288 180
10 0.7 240 41.67 0.30 2100 24 4 288 120
10 0.7 240 41.67 0.40 2800 24 4 288 98
10 0.7 240 41.67 0.50 3500 24 4 288 82
10 0.7 240 41.67 0.60 4200 24 4 288 70
10 0.7 240 41.67 0.70 4900 24 4 288 60
10 0.7 240 41.67 0.80 5600 24 4 288 53
10 0.7 240 41.67 0.90 6300 24 4 288 48
10 0.7 240 41.67 1.00 7000 24 4 288 43
UPS ESTIMATED RUNTIME WITH INTERNAL BATTERIES AND 2 MATCHING BATTERY CABINETS @ .70pf
Rating PF Output
Voltage
Rated I Rated
Load %
Output
Watts
# Batt # Strings Nominal Runtime
10 0.7 240 41.67 0.10 700 24 7 288 300
10 0.7 240 41.67 0.20 1400 24 7 288 300
10 0.7 240 41.67 0.30 2100 24 7 288 240
10 0.7 240 41.67 0.40 2800 24 7 288 165
10 0.7 240 41.67 0.50 3500 24 7 288 135
10 0.7 240 41.67 0.60 4200 24 7 288 112
10 0.7 240 41.67 0.70 4900 24 7 288 98
10 0.7 240 41.67 0.80 5600 24 7 288 90
10 0.7 240 41.67 0.90 6300 24 7 288 82
10 0.7 240 41.67 1.00 7000 24 7 288 72
