1600XP/XPi Series Installation and Operation Manual – 60616-012
14kVA – UH3G2L140C61T / H3BG2L140C61T
(Runtimes are approximate)
UPS ESTIMATED RUNTIME WITH ONLY INTERNAL BATTERIES @ .70pf
Rating PF Output
Voltage
Rated I Rated
Load %
Output
Watts
# Batt # Strings Nominal Runtime
14 0.7 240 58.33 0.10 980 24 2 288 135
14 0.7 240 58.33 0.20 1960 24 2 288 72
14 0.7 240 58.33 0.30 2940 24 2 288 50
14 0.7 240 58.33 0.40 3920 24 2 288 38
14 0.7 240 58.33 0.50 4900 24 2 288 28
14 0.7 240 58.33 0.60 5880 24 2 288 21
14 0.7 240 58.33 0.70 6860 24 2 288 17
14 0.7 240 58.33 0.80 7840 24 2 288 15
14 0.7 240 58.33 0.90 8820 24 2 288 12
14 0.7 240 58.33 1.00 9800 24 2 288 7
UPS ESTIMATED RUNTIME WITH INTERNAL BATTERIES AND 1 MATCHING BATTERY CABINET @ .70pf
Rating PF Output
Voltage
Rated I Rated
Load %
Output
Watts
# Batt # Strings Nominal Runtime
14 0.7 240 58.33 0.10 980 24 5 288 300
14 0.7 240 58.33 0.20 1960 24 5 288 165
14 0.7 240 58.33 0.30 2940 24 5 288 120
14 0.7 240 58.33 0.40 3920 24 5 288 90
14 0.7 240 58.33 0.50 4900 24 5 288 82
14 0.7 240 58.33 0.60 5880 24 5 288 63
14 0.7 240 58.33 0.70 6860 24 5 288 55
14 0.7 240 58.33 0.80 7840 24 5 288 48
14 0.7 240 58.33 0.90 8820 24 5 288 43
14 0.7 240 58.33 1.00 9800 24 5 288 38
UPS ESTIMATED RUNTIME WITH INTERNAL BATTERIES AND 2 MATCHING BATTERY CABINETS @ .70pf
Rating PF Output
Voltage
Rated I Rated
Load %
Output
Watts
# Batt # Strings Nominal Runtime
14 0.7 240 58.33 0.10 980 24 8 288 300
14 0.7 240 58.33 0.20 1960 24 8 288 300
14 0.7 240 58.33 0.30 2940 24 8 288 180
14 0.7 240 58.33 0.40 3920 24 8 288 135
14 0.7 240 58.33 0.50 4900 24 8 288 112
14 0.7 240 58.33 0.60 5880 24 8 288 98
14 0.7 240 58.33 0.70 6860 24 8 288 86
14 0.7 240 58.33 0.80 7840 24 8 288 78
14 0.7 240 58.33 0.90 8820 24 8 288 65
14 0.7 240 58.33 1.00 9800 24 8 288 60
