1600XP/XPi Series Installation and Operation Manual – 60616-012
11.1 Initial Startup (First Power-Up)
The rst time the UPS is activated after being shipped from the factory, the following parameters need
to be set by the customer for site-specic ratings. Input Rated Voltage, Output Rated Voltage, UPS
Date, and UPS Time. Review Sections 13 and 14 before initializing the UPS.
1. Login to the UPS as ADMIN. See Section 14.3 detailed login directions.
2. The input frequency defaults to 60 Hz in, 60 Hz out. Change frequency values only if required.
3. The rst screen displayed during the initial startup sequence requires the operator to select the
nominal Input Voltage.
4. Select from 208V, 230V, or 240V, and press the Write key.
5. If the command has been accepted, the word “Successful” will appear at the bottom left side of the
display.
6. Repeat the process in step 3 in selecting the Rated Output Voltage.
7. Use the keypad to type in the current date in the format: Day mm/dd/yyyy. (e.g. Mon 10/05/2009)
and press Write.
8. Use the keypad to type in the current time in 12 hour format: hh:mm AM (e.g. 12:15 PM) and press
Write.
9. The Main screen is now displayed. Verify the UPS is in BYPASS mode. The mode (lower right side
of the display) should display Bypass. If it does not display Bypass, press and momentarily hold
the STOP button on the Main display.
NOTE: The internal batteries recharge in both Bypass and On-Line modes. As soon as the input
breaker is closed, the internal batteries will begin recharging.
10. With the UPS in bypass mode, cycle power to the UPS as follows:
• At the rear of the UPS switch the main circuit breaker MCCB to OFF.
• Leave the UPS off until the DC bus is safely discharged (approximately 5 – 10 minutes).
• Restart the UPS by switching the main circuit breaker ON.
The table below summarizes the initialization parameters:
ID Command Options
111 Rated Vin Select from 208V, 230V, or 240V, and press Write. (This parameter sets
the multiplier for the Over-/Under voltage detectors.)
215 Rated Vout Select from 208V, 230V, or 240V, and press Write. (This parameter sets
the multiplier for the Over-/Under voltage detectors.)
634 UPS Date Input the date in this format: Mon 10/05/2009 and press Write.
635 UPS Time Input the current time in 12 hour format: 12:15 PM and press Write.
11. After setup is completed, log back in as USER. See section 14.3 for guidance.
11.2 Battery Parameter Settings
Table 11-1 for setting the battery parameters during initial setup for these congurations: Stand-alone
UPS; UPS + 1 Battery Cabinet; UPS + 2 Battery Cabinets.
