STANDARD MODELS: 14 – 22 KVA (CONT’D)
1. nput/output gures rated for 240 volts unless otherwise stated. Output ratings given for 0.85PF are only valid when
the input voltage is greater than 204 volts; otherwise, ratings given for 0.70PF are applicable.
2. At 6600 ft (2000 m) above sea level, output capacity should be derated by 3% per additional 1000 feet elevation.
3. Subject to update without notice.
4. Derate to 18.7 kVA (15.9 kW) for 50 Hz operation.
Capacity 14 kVA (11.9 kW)
1
18 kVA (15.3 kW)
1
22 kVA (18.7 kW)
1, 5
Max Peak Output Current 174 A 225 A 275 A
Inverter Overload Capacity 125%-30 sec./150%-10 sec
Bypass Overload Capacity 125%-10 min./1000%-1 cycle
Crest Factor 3.0
Environment
Operating Temperature 59 – 77 °F
(15 – 25 °C) Recommended
60 Hz 32 – 104 °F (0 – 40 °C)
50 Hz 32 – 91 °F (0 – 33 °C)
Storage Temperature -4 – 104 °F (-20 – 40 °C)
Installation Area
To be installed in a well ventilated area free of airborne dust,
metal particles or ammable gas, allow at least 4 inches on all sides
Operating Humidity 30 – 90% (no condensation)
Altitude < 6600 ft. (2000 m) above sea level
2
Acoustical Noise 50 dB (A) maximum @ 1 meter from front panel
Heat Generation (Typical) 6610 BTU/Hr
3
8499 BTU/Hr
3
10,387 BTU/Hr
3
Operation Diagnosis
Battery Check Performed on start up, by schedule, on-demand (user congurable)
Input OV Protection Standard
Battery Lifetime
UPS calculates battery replacement time based upon
battery ambient temperature (LCD display, LED and beeps)
Internal Temperature UPS gives indication of internal temperature, alarm when high temp
Event Data Storage Registers
32 – Operation, 32 – Backup, 32 – Warnings, 32 – Faults, 32 – Test,
32 – System
Applications
Switches Generator compatible
Bypass Switch
Bypass Disable Static switch <1/4 cycle (50Hz: 5 ms/60Hz: 4.16 ms)
Automatic Retransfer Factory or authorized service center selectable only
Interface/Communications
Real Time clock Real Time Clock with backup Lithium Ion Battery
Schedule Operation
Schedule ON/OFF operation of UPS using optional RemotEye III
communication software
Autostart
Automatic UPS Startup when AC is applied – Option can be enabled or
disabled at user’s discretion
Remote ON/OFF Standard – External terminal
LED Display 3 LED’s indicating On-Line/Fault, Warning, and A/C Input
Operator Interface Interactive Touchscreen
Buzzer Volume Standard (Fixed Volume)

Toshiba 1600XP SERIES Specifications

General

Brand	Toshiba
Model	1600XP SERIES
Category	UPS
Language	English
