Page #15 background image
English - 14 -
Renaming a Channel
Select the channel that you want to rename and select Edit
Name option. Press OK button to continue.
Pressing Left or Right button moves to the previous/next
character. Pressing Up or Down button changes the current
character. Pressing the numeric buttons ‘0...9’ replaces the
highlighted character with the characters printed above the
button one by one as the button is pressed.
When nished, press OK button to save. Press MENU
to cancel.
Locking a Channel
You can press GREEN button to tag/untag all channels;
YELLOW button to tag/untag a single channel.
Select the channel that you want to lock by using Up or
Down buttons.
Select Lock option by using Left or Right buttons. Press
OK button to continue.
You will be asked to enter parental control PIN. Enter the
PIN number.
Note: Default PIN is set to 0000.
Press OK button when the desired channel is highlighted
to lock/unlock the channel. Lock symbol will be displayed
next to the selected channel.
Viewing Info Banner
Press INFO button the information screen will appear
giving details of the channel and programme currently
being viewed.
Whenever you change channel, the TV displays the broadcast
picture along with an information banner at the bottom of the
screen (available only in DTV mode). This will remain on the
screen for a few seconds.
If the selected channel is locked, you must enter the correct
four numeric code to view the channel. “Enter PIN” will be
displayed on the screen in such a case:
Enter the PIN number to continue.
Electronic Programme Guide
Select the on-screen guide by pressing EPG, the guide
screen will appear highlighting details of the channel and
programme currently being viewed. This may take a few
moments to appear.
For information on a highlighted programme, press INFO
button.
For details of other programmes currently available, press
RED or GREEN to scroll up and down the list. As channels
are selected, details of the programme currently being
broadcast will appear.
To set the timer for a selected programme, press the OK
button to select Timers menu.
Press YELLOW or BLUE for advancing to next or previous
day.
Press
(SWAP) button to jump to the current
broadcast.
Renaming a Channel and
Programme Locking
Viewing Info Banner and
EPG
00_MB45_[GB]_3910UK_IDTV_NICKEL9_19740W_(IB_INTERNET)_10068435.indd 1400_MB45_[GB]_3910UK_IDTV_NICKEL9_19740W_(IB_INTERNET)_10068435.indd 14 17.05.2010 16:43:2417.05.2010 16:43:24

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Toshiba 19BV500B and is the answer not in the manual?

Toshiba 19BV500B Specifications

General IconGeneral
Audio systemNICAM
RMS rated power5 W
Number of speakers2
Child lockYes
Audio formats supportedMP3
Image formats supportedJPG
Operating temperature (T-T)5 - 35 °C
Display diagonal19 \
Display brightness250 cd/m²
Display resolution1366 x 768 pixels
Display technologyLCD
Native aspect ratio16:10
Supported video modes720p
Viewing angle, vertical160 °
Contrast ratio (dynamic)8000:1
Screen format adjustments4:3, 16:9
Viewing angle, horizontal170 °
Supported graphics resolutions1280 x 720 (HD 720)
RS-232 ports0
SCART ports quantity1
Card reader integratedNo
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Battery typeAAA
Headphone connectivity3.5 mm
Remote control typeRC-3910
Product colorBlack
LED indicatorsY, Stand-by
AC input voltage220 - 240 V
AC input frequency50 Hz
Power consumption (standby)1 W
Power consumption (typical)45 W
Tuner typeAnalog & digital
Analog signal format systemNTSC, PAL, SECAM
Digital signal format systemDVB-T
Weight and Dimensions IconWeight and Dimensions
Weight (with stand)4500 g
Depth (without stand)63 mm
Width (without stand)460 mm
Height (without stand)340 mm
Weight (without stand)4200 g
