Toshiba 19BV500B User Manual

English - 28 -
Appendix A: PC Input Typical Display Modes
The display has a maximum resolution of 1600 X 1200. The following table is an illustration of some of the typical video
display modes.
Your TV may not support different resolutions. Supported resolution modes are listed below.
If you switch your PC to an unsupported mode, a warning OSD will appear on the screen.
Index
Resolution Frequency
Standard
Supported
Zoom Modes
Hor Ver Ver (Hz)
Hor
(KHz)
1 640 480 60 31.5 VESA 16:9, 4:3
2 640 480 72 37.9 VESA 16:9, 4:3
3 640 480 75 37.5 VESA 16:9, 4:3
4 800 600 56 35.2 VESA 16:9, 4:3
5 800 600 60 37.9 VESA 16:9, 4:3
6 800 600 70 43.8 16:9, 4:3
7 800 600 72 48.1 VESA 16:9, 4:3
8 800 600 75 46.9 VESA 16:9, 4:3
9 832 624 75 49.7 MAC 16:9, 4:3
10 1024 768 60 48.4 VESA 16:9, 4:3
11 1024 768 70 56.5 VESA 16:9, 4:3
12 1024 768 72 57.7 16:9, 4:3
13 1024 768 75 60.0 16:9, 4:3
14 1152 864 70 64.2 VESA 16:9, 4:3
15 1152 864 75 67.5 VESA 16:9, 4:3
16 1152 870 75 68.9 MAC 16:9, 4:3
17 1280 768 60 47.7 VESA 16:9, 4:3
18 1360 768 60 47.7 16:9, 4:3
19 1280 960 60 60.0 VESA 16:9, 4:3
20 1280 1024 60 64.0 VESA 16:9
21 1280 1024 75 80.0 VESA 16:9
22 1600 1200 60 75.0 VESA 16:9
PIN Information
Before connecting any external equipment, turn off all main power switches. If there is no switch, remove the mains plug from
the wall socket. Signal information for Mini D-sub 15 pin connector
Pin No. Signal name Pin No. Signal name Pin No. Signal name
1 R 6 Ground 11 NC
2 G 7 Ground 12 NC
3 B 8 Ground 13 H-sync
4 NC* 9 NC 14 V-sync
5 NC 10 Ground 15 NC
* NC = not connected
00_MB45_[GB]_3910UK_IDTV_NICKEL9_19740W_(IB_INTERNET)_10068435.indd 2800_MB45_[GB]_3910UK_IDTV_NICKEL9_19740W_(IB_INTERNET)_10068435.indd 28 17.05.2010 16:43:2817.05.2010 16:43:28

Toshiba 19BV500B Specifications

General

Audio system	NICAM
RMS rated power	5 W
Number of speakers	2
Child lock	Yes
Audio formats supported	MP3
Image formats supported	JPG
Operating temperature (T-T)	5 - 35 °C
Display diagonal	19 \
Display brightness	250 cd/m²
Display resolution	1366 x 768 pixels
Display technology	LCD
Native aspect ratio	16:10
Supported video modes	720p
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	8000:1
Screen format adjustments	4:3, 16:9
Viewing angle, horizontal	170 °
Supported graphics resolutions	1280 x 720 (HD 720)
RS-232 ports	0
SCART ports quantity	1
Card reader integrated	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Battery type	AAA
Headphone connectivity	3.5 mm
Remote control type	RC-3910
Product color	Black
LED indicators	Y, Stand-by
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	1 W
Power consumption (typical)	45 W
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-T

Weight and Dimensions

Weight (with stand)	4500 g
Depth (without stand)	63 mm
Width (without stand)	460 mm
Height (without stand)	340 mm
Weight (without stand)	4200 g
