Toshiba 21S23B2 User Manual

19
EXT2 SET Menu Option
1
Press MENU on your remote
control.
The on screen display will
appear.
2
Press P▲ or P▼ to select
EXT2 SET menu.
Then press OK.
3
When you connect another TV set or S-Video
VCR etc. to the rear EXT2 socket on your TV
set with a 21 pin Scart lead, you may have to
use the EXT2 SET menu below.
OUTPUT defines what is sent to the other TV
and INPUT describes the type of VCR.
ON/OFF TIMER
SETUP
SOUND
NICAM AUTO OFF
EXT COLOUR AUTO
LANGUAGE
PANEL LOCK ON OFF
EXT2 SET
PRESS : / / OK / MENU / EXIT
ON/OFF TIMER
SETUP
SOUND
NICAM AUTO OFF
EXT COLOUR AUTO
LANGUAGE
PANEL LOCK ON OFF
EXT2 SET
PRESS : / / OK / MENU / EXIT
4
Press P▲ or P▼ to select EXT2
OUTPUT or EXT2 INPUT.
In case of OUTPUT selection
Then press OK to select
TV: the most recent channel
position
MONITOR:
the picture on the
screen
In case of INPUT selection
Then press OK to select
AV: conventional VCR
S-VIDEO:
S-Video VCR
EXT2 SET
EXT2 OUTPUT TV
MONITOR
EXT2 INPUT AV
S-VIDEO
PRESS : / / OK / MENU / EXIT
Press EXIT to remove the picture menu from the screen.
3M50301C P18-21 10/1/06, 9:4919

Toshiba 21S23B2 Specifications

Power

mains supply voltage	230-240 V
power consumption	60 W
standby power consumption	3 W

Operating Environment

operating temperature minimum	5 ˚C
operating temperature maximum	40 ˚C
deflection angle	90 degrees

Display and Audio

picture tube size	21 inches
visible screen size	54.5 cm
sound output	5.0 W x 2

Weight and Dimensions

width	590 mm
depth	492 mm
height	446.5 mm
weight	21.0 kg
