September 1997 © TOSHIBA CORP. 1 - 55 2460 ADJUSTMENT
1.12 Lens Unit
It is impossible to adjust the lens unit. Replace the entire unit with a new one.
Notes 1. Do not touch the screws H (paint lock: 7pcs.) when replacing the lens unit.
2. Take sufficient care when handling the unit not to hold the adjustment portion.
Front side
Rear side
Lens
