2460 MAINTENANCE 2 - 2 September 1997 © TOSHIBA CORP.
PERIODIC INSPECTION CHECK LIST
Clean at Lubricate at Replace Check
80,000 copies 80,000 copies x 1,000 while on
1. Overall unit Z
2. Main blade 80 *1
3. Toner bag 20 Conducted
Cleaner
by key
operator
4. Recovery blade Z > *2
6. Separation claw 80 > Z *3
7. Drum shaft Z or A
Drum 8. Drum 80 *4
9. Ozone filter 80
Original 10. Glass Z *5
holder 11. Original cover Z or A
12. Mirror 1 Z
13. Mirror 2 Z
14. Mirror 3 Z
15. Reflector Z
Optical 16. Lens Z
system 17. Exposure lamp > Z
18. Copy area indicator Z
19. APS ZZ
20. Slider sheet (front, rear) Z or A >
21. Air filter Z > *6
22. Case Z *7
Charger
23. Charger wire 80 > Z *7
24. Terminal contact Z
25. Grid Z 160 *8
26. Overall unit Z
Develop- 27. Developer material 80 *9
er unit 28. Front shield Z > *10
29. Guide roller Z or A >
Laser op- 30. Slit glass Z
tical unit
31. Pick-up roller A 80 >
32. Feed roller A 80 >
33. Separation roller A 80 >
Paper
34.
Paper feed system drive gears W
feed
(tooth faces)
system
35. Aligning roller A >
36. Paper guide Z >
37. Brush Z >
38. Transport belt Z >
39. Separation pad A 80>
Remarks
Item to check
Area
