CHAPTER 2 SPECIFIC INFORMATIONS
SETTING & ADJUSTING DATA
SAFETY INSTRUCTIONS
SERVICE MODE
ADJUSTING ITEMS AND DATAS IN THE SERVICE MODE:
Table-1
Table-2
29"
HIGH VOLTAGE AT MAX BEAM CURRENT: (A) 30.0 kV
MAX HIGH VOLTAGE: (B) 32.0 kV
AC VOLTAGE (C) 110-240 V
BCUT B CUTOFF (B/W) 20H
←
GCUT G CUTOFF (B/W) 20H
←
RDRV R DRIVE 20H
←
GDRV G DRIVE 20H
←
BDRV B DRIVE 20H
←
BRTC SUB BRIGHT CENTER 24H
←
COLC SUB COLOR CENTER NTSC 1EH
←
TNTC SUB TINT CENTER 1EH
←
COLP SUB COLOR CENTER PAL 1DH
←
COLS SUB COLOR CENTER SECAM 1DH
←
SCNT SUB CONTRAST TV 00H
←
SBY SECAM B-Y BLACK OFFSET 01H
←
VPOS 50Hz V-POSITION 1CH
←
HIT HEIGHT 25H
←
VLIN V-LINEARITY 24H
←
HPOS H-POSITION 2BH
←
WID EW WIDTH 31H
←
PARA EW PARABOLA 17H
←
TRAP EW TRAPEZIUM 26H
←
TCNR EW UPPER PARABOLA 15H
←
BCNR EW LOWER PARABOLA 15H
←
HPLL HORIZONTAL PARALLELOGRAM 22H
←
HBOW HORIZONTAL BOW 20H
←
XCAL CRYSTAL CALIBRATION 30H
←
RAGC AGC TAKE-OVER 12H
←
CTR1 CONTROL 1 07H
←
