SPECIFIC INFORMATIONS
CHASSIS AND CABINET REPLACEMENT PARTS LIST
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY PRE-
CAUTION” AND “PRODUCT SAFETY NOTICE” ON PAGE 3 OF THIS MANUAL.
CAUTION: The international hazard symbols “
” in the schematic diagram and the parts list designate components
which have special characteristics important for safety and should be replaced only with types identical to those in the
original circuit or specified in the parts list. The mounting position of replacements is to be identical with originals.
Before replacing any of these components, read carefully the PRODUCT SAFETY NOTICE. Do not degrade the safety
of the receiver through improper servicing.
NOTICE:
• The part number must be used when ordering parts, in order to assist in processing, be sure to include the
Model number and Description.
• The PC board assembly with
*
mark is no longer available after the end of the production.
Model: 29CZ5DE/29CZ5T/29CZ6SI
Capacitors .......... CD : Ceramic Disk PF : Plastic Film EL : Electrolytic
Resistors ............ CF : Carbon Film CC : Carbon Composition MF : Metal Film
OMF : Oxide Metal Film VR : Variable Resistor FR : Fusible Resistor
(All CD and PF capacitors are ±5%, 50V and all resistors, ±5%, 1/6W unless otherwise noted.)
Location Parts No. Description
No.
Location Parts No. Description
No.
[#1: 29CZ5DE]
[#2: 29CZ5T]
[#3: 29CZ6SI]
CAPACITORS
C101 76797479 ELECTROLYTIC 50V 4.7UF M
C102 76109103 CERAMIC CHIP 50V B 0.01UF K
C103 76109103 CERAMIC CHIP 50V B 0.01UF K
C104 #1 76109103 CERAMIC CHIP 50V B 0.01UF K
#3 76109103 CERAMIC CHIP 50V B 0.01UF K
C105 76109103 CERAMIC CHIP 50V B 0.01UF K
C106 76109103 CERAMIC CHIP 50V B 0.01UF K
C107 76109102 CERAMIC CHIP 50V B 1000PF K
C108 76797100 ELECTROLYTIC 50V 10UF M
C109 76797221 ELECTROLYTIC 50V 220UF M
C110 76797221 ELECTROLYTIC 50V 220UF M
C114 76109103 CERAMIC CHIP 50V B 0.01UF K
C116 76109103 CERAMIC CHIP 50V B 0.01UF K
C121 76797100 ELECTROLYTIC 50V 10UF M
C122 76100104 CERAMIC CHIP 25V F 0.1UF Z
C123 76109332 CERAMIC CHIP 50V B 3300PF K
C124 76100104 CERAMIC CHIP 25V F 0.1UF Z
C125 76797229 ELECTROLYTIC 50V 2.2UF M
C127 76797229 ELECTROLYTIC 50V 2.2UF M
C128 76100104 CERAMIC CHIP 25V F 0.1UF Z
C129 76793471 ELECTROLYTIC 10V 470UF M
C131 76109103 CERAMIC CHIP 50V B 0.01UF K
C140 #2 76000445 CHIP JUMPER 1608TYPE
C141 #2 76109103 CERAMIC CHIP 50V B 0.01UF K
C142 #2 76109103 CERAMIC CHIP 50V B 0.01UF K
C144 #2 76797100 ELECTROLYTIC 50V 10UF M
C145 #2 76100104 CERAMIC CHIP 25V F 0.1UF Z
C156 76105120 CERAMIC CHIP 50V CH 12PF J
C157 76105510 CERAMIC CHIP 50V CH 51PF J
C158 76797100 ELECTROLYTIC 50V 10UF M
C159 76100104 CERAMIC CHIP 25V F 0.1UF Z
C201 76109682 CERAMIC CHIP 50V B 6800PF K
C202 76125006 E. CAP 25V 1.5UF REA1R5K1EFC-0511
C203 76503045 PLASTIC FILM 63V 0.22UF J
C204 76795100 ELECTROLYTIC 25V 10UF M
C205 76109223 CERAMIC CHIP 25V B 0.022UF K
C206 76100104 CERAMIC CHIP 25V F 0.1UF Z
C211 76100104 CERAMIC CHIP 25V F 0.1UF Z
C212 76206010 ELECTROLYTIC 50V 1.0UF M 7L 3A
C219 76092729 CERAMIC CHIP 16V B 0.068UF K
C220 76503047 PLASTIC FILM 63V 0.33UF J
C303 76214471 CERAMIC DISC 500V B 470PF K
C308 76669221 ELECTROLYTIC 50V 220UF M
C309 76667102 ELECTROLYTIC 25V 1000UF M
C310 76667222 ELECTROLYTIC 25V 2200UF M 3A
C313 76082061 PLASTIC FILM 100V 0.47UF J
C315 76109102 CERAMIC CHIP 50V B 1000PF K
C321 76109272 CERAMIC CHIP 50V B 2700PF K
C322 76214471 CERAMIC DISC 500V B 470PF K
C327 76100102 CERAMIC CHIP 50V F 1000PF Z
C328 76693104 PLASTIC FILM 100V 0.1UF J
C329 76100102 CERAMIC CHIP 50V F 1000PF Z
C331 76109472 CERAMIC CHIP 50V B 4700PF K
C333 76667222 ELECTROLYTIC 25V 2200UF M 3A
C335 76667221 ELECTROLYTIC 25V 220UF M
C336 76109272 CERAMIC CHIP 50V B 2700PF K
C350 76503043 PLA CAP PCMT36676154
C363 76693104 PLASTIC FILM 100V 0.1UF J
C401 76105151 CERAMIC CHIP 50V CH 150PF J
C402 76693472 PLASTIC FILM 100V 4700PF J
C413 76214821 CERAMIC DISC 500V B 820PF K
C416 76678479 ELECTROLYTIC 200V 4.7UF M
C417 76214391 CERAMIC DISC 500V B 390PF K
C430 76092731 CERAMIC CHIP 16V B 1UF K
C432 76100102 CERAMIC CHIP 50V F 1000PF Z
C435 76794220 ELECTROLYTIC 16V 22UF M
C439 76503125 PLASTIC FILM 400V 0.075UF J
C442 76503298 PLASTIC FILM 315V 0.3UF J
C443 76503194 PLASTIC FILM 1500VH 0.01UF H
C444 76503228 PLASTIC FILM 1500VH 6800PF H
C447 76679220 ELECTROLYTIC 250V 22UF M 3A
C448 76640908 ELECTROLYTIC 160V 33UF M 3A LI
C449 76667102 ELECTROLYTIC 25V 1000UF M
C463 76212222 CERAMIC DISC 50V B 2200PF K
C464 76073124 ELECTROLYTIC 100V 10UF M
C467 76503159 PLASTIC FILM 630V 0.039UF J
C470 76766101 ELECTROLYTIC 50V 100UF M
C4700 76109332 CERAMIC CHIP 50V B 3300PF K
C4703 76764221 ELECTROLYTIC 25V 220UF M
C4712 76109332 CERAMIC CHIP 50V B 3300PF K
C4717 76000445 CHIP JUMPER 1608TYPE
C472 76503049 PLASTIC FILM 63V 0.47UF J
C475 76100103 CERAMIC CHIP 50V F 0.01UF Z
C501 76793471 ELECTROLYTIC 10V 470UF M
C502 76092730 CERAMIC CHIP 16V B 0.1UF K
C503 76203100 ELECTORLYTIC 16V 10UF M 7L 3A
C504 76100104 CERAMIC CHIP 25V F 0.1UF Z
C505 76793471 ELECTROLYTIC 10V 470UF M
C506 76100104 CERAMIC CHIP 25V F 0.1UF Z
C507 76793471 ELECTROLYTIC 10V 470UF M
C508 76100104 CERAMIC CHIP 25V F 0.1UF Z
