APPENDIX 2 MESSAGES AND LEDS
ENGLISH VERSION EO1-33034
APPENDIX 2 MESSAGES AND LEDS
EA2- 1
APPENDIX 2 MESSAGES AND LEDS
Appendix 2 describes the LCD messages displayed on the operation panel.
Symbols in the message
1: : The LED is illuminated. ~: The LED is flashing. z: The LED is unlit.
2: ****: the number of unprinted media. Up to 9999 (in pieces)
3: %%%%%%%: ATA Card’s remaining memory 0 to 9999999 (in K bytes)
4: ###: Flash memory card remaining memory for PC save area: 0 to 895 (in K bytes)
5: &&&&: Remaining flash memory capacity for storing writable characters 0 to 3147 (in K bytes)
LED Indication
No.
LCD Message
POWER ONLINE ERROR
Printer Status
Restoration by
RESTART ke
Yes/No
Acceptance of
Status Request
Reset Command
Yes/No
ON LINE
z
In online mode ----- Yes
1
ON LINE
~ z
In online mode (The printer in
communication)
----- Yes
2
HEAD OPEN
z z
The print head block is opened in online
mode.
----- Yes
3
PAUSE ****
z z
The printer is paused. Yes Yes
4
COMMS ERROR
z
A parity, overrun, or framing error has
occurred during communication through
the RS-232C.
Yes Yes
5
PAPER JAM ****
z
The media is jammed during paper feed. Yes Yes
6
CUTTER ERROR****
z
A problem has occurred with the cutter
module.
Yes Yes
7
NO PAPER ****
z
The media has run out, or the media is
not loaded properly.
Yes Yes
8
NO RIBBON ****
z
The ribbon has run out. Yes Yes
9
HEAD OPEN ****
z
Feed or printing was attempted with the
print head block open.
Yes Yes
10
HEAD ERROR
z
There is a problem with the print head. Yes Yes
11
EXCESS HEAD TEMP
z
The print head is overheated. No Yes
12
RIBBON ERROR****
z
The ribbon has been torn. A problem
has occurred with the sensor that
determines the torque for the ribbon
motor.
Yes Yes
13
REWIND FULL ****
z
An overflow error has occurred in the
rewinder unit.
Yes Yes
14
SAVING%%%%%%%
or
SAVING ###&&&&
z
In writable character or PC command
save mode
----- Yes
15
FLASH WRITE ERR.
z
An error has occurred while writing to
flash memory or ATA card.
No Yes
16
FORMAT ERROR
z
An erase error has occurred in
formatting the flash memory or ATA
card.
No Yes
17
FLASH CARD FULL
z
Data cannot be stored because the flash
memory or ATA card is full.
No Yes
18
Display of error
message (See Notes.)
z
A command error has occurred in
analyzing the command.
Yes Yes
19
POWER FAILURE
z A power failure has occurred. No No
20
INTIALIZING…
z z A flash memory card is being initialised. ----- -----
21
100BASE LAN
INITIALIZING…
z z
100 Base LAN Board is being
initialized.
----- -----
To Next Page
