1. PRODUCT OVERVIEW

ENGLISH VERSION

EO1-33034

1.1 Introduction

E1- 1

1. PRODUCT OVERVIEW

1.1 Introduction

1.2 Features

1.3 Unpacking

Thank you for choosing the TEC B-SX4T series thermal printer. This

Owner’s Manual contains from general set-up through how to confirm

the printer operation using a test print, and should be read carefully to

help gain maximum performance and life from your printer. For most

queries please refer to this manual and keep it safe for future reference.

Please contact your TOSHIBA TEC representative for further

information concerning this manual.

This printer has the following features:

• The print head block can be opened providing smooth loading of

media and ribbon.

• Various kinds of media can be used as the media sensors can be

moved from the centre to the left edge of the media.

• When the optional interface board is installed, Web functions such as

remote maintenance and other advanced network features are

available.

• Superior hardware, including the specially developed 8 dots/mm (203

dots/inch) thermal print head which will allow very clear print at a

printing speed of 76.2 mm/sec. (3 inches/sec.), 152.4 mm/sec. (6

inches/sec.), or 254.0 mm/sec. (10 inches/sec.).

• Besides the optional Cutter Module, there is also an optional Strip

Module, Ribbon Saving Module, PCMCIA Interface Board,

Expansion I/O Interface Board, LAN Interface Board, and the USB

Interface Board.

Unpack the printer as per the Unpacking Instructions supplied with the

printer.

NOTES:

1. Check for damage or

scratches on the printer.

However, please note that

TOSHIBA TEC shall have no

liability for any damage of

any kind sustained during

transportation of the product.

2. Keep the cartons and pads

for future transportation of

the printer.

Other manuals for Toshiba B-SX4T Series

Specification374 pages

Need help?

Do you have a question about the Toshiba B-SX4T Series and is the answer not in the manual?

Toshiba B-SX4T Series Specifications

General

Resolution	203 dpi (8 dots/mm)
Power Supply	AC 100-240V, 50/60 Hz
Print Method	Direct Thermal / Thermal Transfer
Print Width	104 mm
Print Speed	Up to 6 ips (inches per second)
Interfaces	Serial, Parallel, USB, LAN
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Supported Barcodes	UPC/EAN/JAN, Code 39, Code 93, Code 128, EAN 128, NW7, Interleaved 2 of 5, Industrial 2 of 5, Postnet, RM4SCC, KIX-Code, GS1 DataBar, Postal Code, Data Matrix, PDF417, Maxicode, QR Code
Humidity	20% to 85% (non-condensing)
