1-2. Outdoor Unit
Model Outdoor unit RAV-GP 561ATW* 801ATW*
Power supply 220 - 240 V ~, 50 Hz
Compressor
Type Hermetic compressor
Motor (kW) 1.10 2.00
Pole 4 6
Refrigerant charged (kg) 1.35 1.9
Refrigerant control Pulse motor valve
Length of refrigerant
pipe
Max. (m) 50 50
Min. (m) 3 3
Height
difference
Outdoor lower (m) 30 30
Outdoor high (m) 30 30
Outer dimension
Height 630 1050
Width 799 1010
Depth 299 370
Appearance
Silky shade
(Munsell 1Y8.5/0.5)
Total weight (kg) 45 74
Heat exchanger Finned tube
Fan unit
Fan Propeller fan
Standard air flow (m³/min) 37.5 53
Motor (W) 43 60
Connecting pipe
(Outdoor unit side)
Gas side (mm) 12.7 15.9
Liquid side (mm) 6.4 9.5
Sound pressure level Cooling/Heating (dB(A)) 46/48 46/48
Sound power level Cooling/Heating (dB(A)) 63/65 63/66
Outside air temperature: Cooling (°C) -15 to 52
Outside air temperature: Heating (°C) -27 to 15
