45
Trouble-
Specifications
Item Contents
Rated Power Supply 120V, 60Hz AC
Rated Power Consumption 1281W
Standard Power Consumption per Hour 22Wh
Power Supply Cord Length 3 feet (1.0m)
Flush Volume 1.6 gpf (6L), 1.2 gpf (4.5L) light flush
Flush Type "Cyclone" Siphon jet
Bowl Style Elongated
Washlet Rear 9-14.5 oz/min (0.27 ~ 0.43L/min ) (29 Psi Max)
Wand Flow Rate Soft 9-14.5 oz/min (0.27 ~ 0.43L/min ) (29 Psi Max)
Front 9.5-14.5 oz/min (0.29 ~ 0.43L/min) (29 Psi Max)
Water Temperature 86-104 ºF (30 ~ 40 ºC)
Heater Capacity 1200W (Instantaneous)
Safety Devices Temperature Fuse, Bimetal sensor (auto reset), and Float Switch
(prevent boil)
Dryer Temperature 104-138 ºF (40 ~ 60 ºC)
Air Volume 10.5 ft
3
/ min (0.30m
3
/min)
Heater power 350 W
Safety Devices Temperature Fuse
Heated Seat Temperature 81-97 ºF (27 ~ 36 ºC) ( 79 ºF (26 ºC) for Auto Energy Saving)
Heater Power 50W
Safety Temperature Fuse
Deodorizer Catalyst Activated Oxygen
Air Volume 5.5 ft
3
/min (0.16m
3
/min)
Water Supply Pressure 20-80 PSI, Static (Use a minimum water supply pressure of 10 PSI
(0.07 MPa) flowing)
Water Supply Temperature 32 - 96 ºF (0 ~ 35 ºC)
Allowable Temperature Range 32 - 104 ºF (0 ~ 40 ºC)
Product Dimensions Width: 16" (404mm), Depth: 25 7/8" (657mm), Height: 20 3/8" (518mm)
Product Weight 81.4 Lbs (37kg) (Washlet Unit: 15.4 Lbs (7kg), Toilet: 66 Lbs (30kg))
