25
Chapter 5
TP-Link Cloud Service
from the same router as Users. All accounts can monitor and manage the router locally
or remotely, but user accounts cannot:
Reset the router to its factory default settings either on the web management page
or in the Tether app.
Add/remove other TP-Link IDs to/from the router.
5. 3. 1. Add TP-Link ID to Manage the Router
1. Visit http://tplinkwifi.net, and log in with your TP-Link ID.
2. Go to Advanced > TP-Link ID, and focus on the Bound Accounts section.
3. Click
, enter another TP-Link ID as needed and click SAVE.
Note: If you need another TP-Link ID, please register a new one via the Tether app. Refer to Manage the Router via the
TP-Link Tether App to install the app and register a new TP-Link ID.
4. The new TP-Link ID will be displayed in the Bound Accounts table as a User.
5. 3. 2. Remove TP-Link ID(s) from Managing the Router
1. Visit http://tplinkwifi.net, and log in with your TP-Link ID.
2. Go to Advanced > TP-Link ID, and focus on the Bound Accounts section.
3. Tick the checkbox(es) of the TP-Link ID(s) you want to remove and click Unbind.

Table of Contents

Other manuals for TP-Link Archer AX73

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TP-Link Archer AX73 and is the answer not in the manual?

TP-Link Archer AX73 Specifications

General IconGeneral
Modulation1024-QAM, OFDM
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standardWi-Fi 6 (802.11ax)
WLAN data transfer rate (max)5400 Mbit/s
WLAN data transfer rate (first band)4804 Mbit/s
WLAN data transfer rate (second band)574 Mbit/s
MU-MIMO technologyYes
Memory card slot(s)-
Ethernet LAN (RJ-45) ports4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Antennas quantity6
Processor cores3
Processor frequency1500 MHz
SIM card slotNo
WAN connection typeRJ-45
Product typePortable router
Product colorBlack
Output current2.5 A
Output voltage12 V
Power source typeDC
Security algorithmsWPA, WPA-Enterprise, WPA2, WPA2-Enterprise, WPA3
Supported network protocolsIPv4, IPv6
Cables includedLAN (RJ-45)
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 90 %
Harmonized System (HS) code85176990
Sustainability certificatesRoHS, Federal Communications Commission (FCC), CE
Package depth265 mm
Package width415 mm
Package height90 mm
Package weight1490 g
Weight and Dimensions IconWeight and Dimensions
Depth147.2 mm
Width272.5 mm
Height49.2 mm
