48
Chapter 9
USB Settings
Windows
computer
Method 2:
Open the Windows Explorer (or go to Computer) and type the server
address \\tplinkwifi.net or ftp://tplinkwifi.net in the address bar, then
press Enter.
Mac
1 ) Select Go > Connect to Server.
2 ) Type the server address smb://tplinkwifi.net.
3 ) Click Connect.
4 ) When prompted, select the Guest radio box. (If you have set up a
username and a password to deny anonymous access to the USB
disks, you should select the Registered User radio box. To learn how
to set up an account for the access, refer to To Set Up Authentication
for Data Security.)
Tablet
Use a third-party app for network files management.
Tips:
You can also access your USB storage device by using your Network/Media Server Name as the server address. Refer
to To Customize the Address of the USB Storage Device to learn more.
9. 1. 2. Access the USB Device Remotely
You can access your USB disk outside the local area network. For example, you can:

Table of Contents

Other manuals for TP-Link Archer AX73

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TP-Link Archer AX73 and is the answer not in the manual?

TP-Link Archer AX73 Specifications

General IconGeneral
Modulation1024-QAM, OFDM
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standardWi-Fi 6 (802.11ax)
WLAN data transfer rate (max)5400 Mbit/s
WLAN data transfer rate (first band)4804 Mbit/s
WLAN data transfer rate (second band)574 Mbit/s
MU-MIMO technologyYes
Memory card slot(s)-
Ethernet LAN (RJ-45) ports4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Antennas quantity6
Processor cores3
Processor frequency1500 MHz
SIM card slotNo
WAN connection typeRJ-45
Product typePortable router
Product colorBlack
Output current2.5 A
Output voltage12 V
Power source typeDC
Security algorithmsWPA, WPA-Enterprise, WPA2, WPA2-Enterprise, WPA3
Supported network protocolsIPv4, IPv6
Cables includedLAN (RJ-45)
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 90 %
Harmonized System (HS) code85176990
Sustainability certificatesRoHS, Federal Communications Commission (FCC), CE
Package depth265 mm
Package width415 mm
Package height90 mm
Package weight1490 g
Weight and Dimensions IconWeight and Dimensions
Depth147.2 mm
Width272.5 mm
Height49.2 mm
