TP-Link RE355 User Manual

Connect the Extender to the Internet
Immediately press the RE button on your extender. The LED
should change from flashing to solid, showing that WPS connection is
successful.
If you are connecting the extender to a dual-band router but only
2.4GHz or 5GHz LED is on, repeat step 1 and 2 again to connect the
other band.
Relocate
Plug the extender into an electrical outlet about halfway between your
router (Host Network) and the Wi-Fi dead zone.
Wait until the LED is lit with a solid blue. If not, relocate the
extender closer to the router to achieve a good (or better) signal quality.
Enjoy!
The extender shares the same wireless network name (SSID) and wireless
password as your router.
For more information about using WPS on your router,
please refer to the router manufacturer's user guide.
 If the RE LED does not change from flashing to solid,
please refer to Using your Web Browser.
 Some ISP gateways disable the WPS function by
default, if the WPS method fails, please refer to Using
your Web Browser.

TP-Link RE355 Specifications

General

Type	-
Windows operating systems supported	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Wi-Fi data rate (max)	867 Mbit/s
Product color	White
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 30 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Ethernet LAN (RJ-45) ports	1
Power consumption (typical)	9 W
Antennas quantity	3
Antenna gain level (max)	3 dBi
Sustainability certificates	RoHS

Weight and Dimensions

Depth	125 mm
Width	202 mm
Height	86 mm
