TP-Link RE355 User Manual

Manage the Extended Network and Security Settings
This chapter covers the following topics:
 Extend another Network
 Extender Settings
 Manage the Extender’s Wi-Fi Security Settings
 Change the Extender’s IP Address
 DHCP Server
If you want to extend another network, you can refer to the following steps to
finish it quickly.
Launch a web browser and type in http://tplinkrepeater.net，then go to
Settings->Wireless->Connect to Network webpage.
Enable Connect to 2.4GHz/5GHz Network. Then click Wireless
Scanner to scan the network you want to extend.
3

TP-Link RE355 Specifications

General

Type	-
Windows operating systems supported	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Wi-Fi data rate (max)	867 Mbit/s
Product color	White
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 30 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Ethernet LAN (RJ-45) ports	1
Power consumption (typical)	9 W
Antennas quantity	3
Antenna gain level (max)	3 dBi
Sustainability certificates	RoHS

Weight and Dimensions

Depth	125 mm
Width	202 mm
Height	86 mm
