TP-Link SafeStream TL-ER6020 User Manual

-7-

LEDs
LED Status Indication
On The Router is powered on
PWR
Off The Router is powered off or power supply is abnormal
Flashing The Router works properly
SYS
On/Off The Router works improperly
On There is a device linked to the corresponding port
Off There is no device linked to the corresponding port
Link/Act
Flashing The corresponding port is transmitting or receiving data
On (Green) The linked device is running at 1000Mbps
On (Yellow) The linked device is running at 100Mbps
Speed
Off
There is no device linked to the corresponding port or the
linked device is running at 10Mbps
On The port is working in DMZ mode
DMZ
Off The port is working in LAN mode

Interface Description
Interface Port Description
WAN 1~2
The WAN port is for connecting the Router to a DSL/Cable
modem or Ethernet by the RJ45 cable
LAN 1~3
The LAN port is for connecting the Router to the local PCs or
switches by the RJ45 cable
DMZ 3 The DMZ port is for connecting the Router to the servers
Console N/A
The Console port is for connecting with the serial port of a
computer or terminal to monitor and configure the Router

Reset button
Use the button to restore the Router to the factory defaults. With the Router powered on, use a pin to
press and hold the Reset button (about 4~5 seconds). After the SYS LED goes out, release the Reset
button. If the SYS LED is flashing with a high frequency about two or three seconds, it means the Router
is restored successfully.

TP-Link SafeStream TL-ER6020 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
VPN tunnels quantity	50
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Maximum indoor range	100 m
RS-232 ports	1
Ethernet LAN (RJ-45) ports	3
Form factor	1U
USB ports quantity	0
Management platform	Web/CLI/Telnet
Filtering description	MAC, URL/Keywords, WebContent
Compatible operating systems	Microsoft Windows 98SE, NT, 2000, XP, Vista, Windows 7\\r MAC OS\\r NetWare, UNIX, Linux
Routing protocols	RIP-1, RIP-2
Supported protocols	IPsec/PPTP/L2TP
Supported network protocols	TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DNS, IPsec, PPTP, L2TP
VPN support	50 IPsec VPN Tunnels LAN-to-LAN, Client-to-LAN Main, Aggressive Negotiation Mode DES, 3DES, AES128, AES192, AES256 Encryption Algorithm MD5, SHA1 Authentication Algorithm IPsec NAT Traversal (NAT-T) Dead Peer Detection (DPD) Perfect Forward Secrecy (PFS) 16 PPTP VPN Tunnels PPTP VPN Server/Client PPTP with MPPE Encryption 16 L2TP VPN Tunnels L2TP VPN Server/Client L2TP over IPsec
NAT functionality	One-to-One NAT\\r Multi-nets NAT\\r Virtual Server, DMZ Host, Port_Triggering, UPnP\\r FTP/H.323/SIP/IPsec/PPTP ALG
Security algorithms	128-bit AES, 256-bit AES, 3DES, DES
Authentication method	MD5, SHA-1
Network Address Translation (NAT) sessions (max)	30000
Flash memory	16 MB
Certification	CE, FCC, RoHS
Internal memory	128 MB
Internal memory type	DDR2
Mac operating systems supported	macOS
Windows operating systems supported	Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power over Ethernet (PoE)	No
Power consumption (typical)	- W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Product color	Black
Sustainability certificates	RoHS
Package depth	250 mm
Package width	400 mm
Package height	80 mm
Package weight	1810 g

Weight and Dimensions

Depth	180 mm
Width	294 mm
Height	44 mm
Weight	- g
