TP-Link SafeStream TL-ER6020 User Manual

-153-
5.4.3 sys
The sys command is used for system management, including Backup and Restore, Factory Default,
Reboot, Firmware Upgrade and so on.
TP-LINK # sys reboot
This command will reboot system, Continue?[Y/N]
Reboot the system. Y means
YES, N means NO.
TP-LINK # sys restore
This command will restore system, Continue?[Y/N]
Restore to factory default. Y
means YES, N means NO.
TP-LINK # sys export config
Server address: [192.168.1.101]192.168.1.100
Username: [admin]ftp
Password: [admin]ftp
File name: [config.bin]
Export the configuration file.
Example: There is a FTP
server with IP address of
192.168.1.100 and both the
user name and password of
which is ftp. To save the
current configuration file with
the default name as
config.bin to this FTP server,
follow the configuration on
the left.
Try to save the configuration file < config.bin > ...
Save configuration file < config bin > succeed, file size is 7104 bytes.
Note:
● FTP service is required for importing or exporting configuration files and system upgrade. The
parameter Server address is the IP address of the host to provide FTP service,
Username/Password is the Username/Password to login the FTP service and File name is the
name of the configuration file (change the file name if the configuration file with the same name is
existed).
● The parameters in the brackets are default setting and you can enter the actual parameters
behind them. Press Enter key directly if there are no changes.
● TL-ER6020 connects to the FTP server using port 21 by default.

TP-Link SafeStream TL-ER6020 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
VPN tunnels quantity	50
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Maximum indoor range	100 m
RS-232 ports	1
Ethernet LAN (RJ-45) ports	3
Form factor	1U
USB ports quantity	0
Management platform	Web/CLI/Telnet
Filtering description	MAC, URL/Keywords, WebContent
Compatible operating systems	Microsoft Windows 98SE, NT, 2000, XP, Vista, Windows 7\\r MAC OS\\r NetWare, UNIX, Linux
Routing protocols	RIP-1, RIP-2
Supported protocols	IPsec/PPTP/L2TP
Supported network protocols	TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DNS, IPsec, PPTP, L2TP
VPN support	50 IPsec VPN Tunnels LAN-to-LAN, Client-to-LAN Main, Aggressive Negotiation Mode DES, 3DES, AES128, AES192, AES256 Encryption Algorithm MD5, SHA1 Authentication Algorithm IPsec NAT Traversal (NAT-T) Dead Peer Detection (DPD) Perfect Forward Secrecy (PFS) 16 PPTP VPN Tunnels PPTP VPN Server/Client PPTP with MPPE Encryption 16 L2TP VPN Tunnels L2TP VPN Server/Client L2TP over IPsec
NAT functionality	One-to-One NAT\\r Multi-nets NAT\\r Virtual Server, DMZ Host, Port_Triggering, UPnP\\r FTP/H.323/SIP/IPsec/PPTP ALG
Security algorithms	128-bit AES, 256-bit AES, 3DES, DES
Authentication method	MD5, SHA-1
Network Address Translation (NAT) sessions (max)	30000
Flash memory	16 MB
Certification	CE, FCC, RoHS
Internal memory	128 MB
Internal memory type	DDR2
Mac operating systems supported	macOS
Windows operating systems supported	Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power over Ethernet (PoE)	No
Power consumption (typical)	- W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Product color	Black
Sustainability certificates	RoHS
Package depth	250 mm
Package width	400 mm
Package height	80 mm
Package weight	1810 g

Weight and Dimensions

Depth	180 mm
Width	294 mm
Height	44 mm
Weight	- g
