Loading...How to restore TP-Link Wireless Access Point to factory default settings?
To restore your TP-Link Wireless Access Point to its factory default settings, power it on, then use a pin to press and hold the WPS/RESET button on the rear panel for more than 8 seconds, then release it.
What to do if I forget the password for my TP-Link Wireless Access Point?
First, try using the default username and password: admin, admin. If that doesn't work, refer to the file you saved in step 6 of the Quick Setup when you initially configured the device, as it contains your configured username and password. Alternatively, you can restore the Access Point to its factory default settings as described in the manual and reconfigure it following the Quick Setup instructions.
What to do if I cannot access the web-based configuration page of my TP-Link TL-WA901ND?
First, ensure you've entered the correct address, which is http://tplinkap.net, in your browser's address bar. Next, verify your hardware connection by checking the LAN LED on the front panel of your TP-Link Wireless Access Point. A green light indicates a good connection. If not, double-check your hardware connections. Also, ensure your wired device’s IP address is set to 'Obtain an IP address automatically'.
General| Security algorithms | 64-bit WEP, 128-bit WEP, 152-bit WEP, WPA, WPA2, WPA2-PSK |
|---|---|
| MAC address filtering | Yes |
| Service Set Identifier (SSID) features | SSID broadcast on/off |
| Antenna features | Detachable antenna |
| Antennas quantity | 3 |
| Antenna connector type | RP-SMA |
| Antenna gain level (max) | 5 dBi |
| 5 GHz | No |
| Modulation | - |
| Frequency band | 2.4 - 2.4835 GHz |
| Number of users | - user(s) |
| Channels quantity | - channels |
| Networking standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Receiver sensitivity | 270M: -68dBm@10% PER 130M: -68dBm@10% PER 108M: -68dBm@10% PER 54M: -68dBm@10% PER 11M: -85dBm@8% PER 6M: -88dBm@10% PER 1M: -90dBm@8% PER |
| Wi-Fi data rate (max) | 450 Mbit/s |
| Ethernet LAN data rates | 10, 100 Mbit/s |
| Input current | 1 A |
| AC input voltage | 12 V |
| Power consumption (typical) | 5.8 W |
| Placement | Table, Wall |
| Certification | CE, FCC, RoHS |
| Product color | White |
| WAN connection | Ethernet (RJ-45) |
| USB 2.0 ports quantity | 0 |
| Ethernet LAN (RJ-45) ports | 1 |
| Cables included | LAN (RJ-45) |
| Compatible operating systems | Windows XP / Vista / 7 / 8 |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 90 % |
| Operating relative humidity (H-H) | 10 - 90 % |
Weight and Dimensions| Depth | 129.9 mm |
|---|---|
| Width | 194.8 mm |
| Height | 36.2 mm |
Details on the TL-WA901ND's capabilities and technical specs.
Identification of physical ports and indicators.
Requirements and preparation steps before setup.
Physical connection instructions for the access point.
Guided initial configuration process.
Logging into the device's management page.
Configuring LAN IP, DHCP, and DNS.
Setting up SSID, channels, modes, and encryption.
Firmware updates, reboot, logs, and password.
