Trane
6200 Troup Highway
Tyler, TX 75707
www.trane.com
For more information contact
your local dealer (distributor)
The manufacturer has a policy of continuous product and product data improvement, and it reserves the
right to change design and specifications without notice.
SUPPLEMENTARY HEATERS CHECKOUT PROCEDURES,
IF USED DOES HEATER REQUIRE A SPECIAL CIRCUIT?
SEE “LIMITATIONS AND RECOMMENDATIONS”
1. Be sure the disconnect switch is “OFF”, and safety label (if any) is attached ........................................... [ ]
2. Check on field wiring for tight connections and grounding according to codes ........................................ [ ]
3. Check circuit protection for proper size per nameplate specifications ..................................................... [ ]
4. Check control box panel — in place and secured ....................................................................................... [ ]
NOTE: OPERATION OF HEATERS MUST BE CHECKED DURING THE OPERATION CHECK OF THE TOTAL
SYSTEM.
CHECKOUT PROCEDURES
After installation has been completed, it is recommended that the Air Handler be checked against the follow-
ing checklist.
1. Make sure power is “OFF” at power
disconnect switch ................................................. [ ]
2. Check all field wiring for tight connections. See
that grounding of unit is in accord with code ..... [ ]
3. Make sure unit suspension (if used) is secure
and that there are no tools or loose debris in,
around or on top of the unit ................................ [ ]
4. Check all duct outlets; they must be open
and unrestricted .................................................. [ ]
5. Check drain lines and be sure all joints are tight
............................................................................. [ ]
6. Make sure secondary drain pan is installed ....... [ ]
7. Check power supply for correct requirements
per unit nameplate .............................................. [ ]
8. Check filters for proper size. Inform owner
of proper procedure for removal and
reinstallation ....................................................... [ ]
9. Energize the system and carefully observe its
operation; make any necessary adjustment ....... [ ]
10. Instruct owner, engineer (if possible) on proper
operating procedure and leave Use and Care
Manual with owner ............................................. [ ]
Installer’s Guide
J. CHECKOUT PROCEDURE
1. Check the Air Handler operation and installation in
accordance with these instructions below.
2. “Operational Procedure” for the system installation
can be found in the outdoor unit installer guide and
will be compatible with this Air Handler.
CAUTION
!
Cardboard packing material must be removed from in-
side the blower assembly before starting the unit.
Failure to do so may cause indoor blower motor fail-
ure.
WARNING
!
TO PREVENT INJURY OR DEATH DUE TO ELECTRICAL
SHOCK OR CONTACT WITH MOVING PARTS, LOCK
UNIT DISCONNECT SWITCH IN OPEN POSITION
BEFORE SERVICING UNIT.
